8GK9532-8KK20 mounting plate
Код товара: 532118
9968,79 грн з ПДВ
ALPHA, mounting panel, W: 500 mm, H: 1350 mm cabinet-height without
Виробник |
---|
ALPHA 400 DIN cabinet-high mounting plate H = 1350 mm, W = 500 mm, without cover The ALPHA distribution board – a complete system of wall-mounted and floor-mounted distribution boards for installing devices up to 1250 A.ALPHA distribution systems are tested according to IEC 61439. Due to the modular design and a common platform structure, the device-specific installation kits can be integrated into different distributor variants. This facilitates easy planning and installation. Equipping is done individually and on a project-specific basis. The SIMARIS configuration software providessupport from planning to documentation of standard and power distribution boards.ALPHA distribution systems are available in a wide range of designs and many special colors. Glass and steel door options are available.ALPHA – the system concept counts.
International product number (GTIN): 4001869262826
Universal product code (UPC):
Alternative product number: 8GK9532-8KK20
Product ID of the manufacturer: 8GK95328KK20
Manufacturer type description: mounting plate
Ключові слова: Mounting angle bracket, Mounting accessories (enclosure/cabinet), 482.6 mm (19 inch) mounting angle bracke, Fastening parts/-set, 19 inch mounting angle bracket, Adaptation for wiring systems, 482.6 mm (19 inch) mounting set, Fastening profile, 19 inch mounting set, Mounting bracket
Special product status:
Classification system: ETIM-8.0
Group reference: EC002625
